Identification Number

he following shows how to create an identification number for NT88H.An identification number can also be created by using the identification number selection tool.

Some products are not shown in the catalogue. Also, modifications can be made to meet your requirements. Please do not hesitate to make inquiries.

Pick Up

NT・・・H Features

IKO Nano Linear NT・・・H is a direct-drive moving-magnet type positioning table, which has magnets and an optical linear scale incorporated into a moving table made of steel, and stator coils and linear scale head incorporated in a steel bed. For guiding parts of the table, an IKO Crossed Roller Way is used in combination with a linear motor and a high-resolution linear encoder to facilitate highly accurate positioning.
Furthermore, except for the linear motion rolling guides, mechanical contact is completely eliminated by adopting the unique design of a wireless moving table in which the linear scale sensor is arranged on the bed. Therefore, the table generates very little dust and provides a high level of cleanliness.
IKO Nano Linear NT・・・H is most suitable for use as a compact positioning mechanism for semiconductor and liquid crystal related equipment and measuring instrument and assembly systems where cleanliness is essential.
